UNI-T UT301A+ Infrared Thermometer, -32°C~420°C, Adjustable Emissivity, Color LCD, Data Logging

English Manual

Professional Infrared Thermometer with Advanced Features
The UNI-T UT301A+ is a high-precision infrared thermometer designed for industrial and professional use. Featuring a wide temperature range (-32°C to 420°C / -25.6°F to 788°F) and adjustable emissivity (0.10-1.0), it delivers accurate non-contact temperature measurements for various applications.

Key Features:

• Wide Temperature Range: -32°C to 420°C (-25.6°F to 788°F)
• High Accuracy: ±1.5°C or ±1.5% (whichever is greater)
• 12:1 Distance-to-Spot Ratio: Measure safely from a distance
• Single-Point Laser Targeting: Precise measurement area indication
• Adjustable Emissivity: 0.10-1.0 (stores 5 preset values)
• Color LCD Display: Clear, intuitive readings
• Data Logging: Stores max/min/avg/difference values
• Audible & Visual Alarms: LED and buzzer alerts for out-of-range temps
• Trigger Lock: Continuous monitoring capability
• Tripod Mount: For hands-free operation
• Fast Response: ≤250ms (95% reading)

Technical Specifications:

• Resolution: 0.1°C/°F
• Repeatability: ±0.7°C or ±0.7%
• Spectral Response: 8μm-14μm
• Laser: Class II (<1mW, 630-670nm)
• Power: 9V battery (6F22, included)
• Dimensions: 161.5×90×48mm
• Weight: 204g

Applications:

• Industrial equipment monitoring
• Electrical maintenance
• HVAC system diagnostics
• Mechanical engineering
• Quality control processes

Package Includes:

• 1×UT301A+ Infrared Thermometer
• 9V Battery
• Carrying Pouch
• User Manual
• Warranty Card

Why Choose UT301A+?
✔ Professional-Grade Accuracy with adjustable emissivity
✔ Advanced Features like data logging and alarms
✔ Industrial Durability with 1m drop protection
✔ Color Display for easy reading
✔ Versatile Applications across multiple industries
