ET5300A Programmable DC Electronic Load 200W 30A Single-Channel Battery Insulation Resistance Tester Power Tool Accessories load tester

ET5300A Programmable DC Electronic Load 200W 30A Single-Channel Battery Insulation Resistance Tester Power Tool Accessories load tester

$285.99

ET5300A Programmable DC Electronic Load 200W 30A Single-Channel Battery Insulation Resistance Tester Power Tool Accessories load tester

$285.99

ET5300A Programmable DC Electronic Load: 200W High-Precision for Single-Channel Testing

Tired of low-precision loads ruining power device test data? The ET5300A delivers 200W power, 0-150V voltage, 0-30A current + 1mV/1mA high resolution—ideal for chargers, switch power supplies, batteries, and LED testing, plus lab R&D and education!

User-Friendly & Durable Design

  • Clear Visualization: 3.5-inch TFT LCD with bilingual (Chinese/English) display, showing voltage, current, power, and test mode data at a glance.
  • Easy Operation: Intuitive interface + one-key entry/exit; built-in key lock prevents accidental misoperation during critical tests, even for beginners.
  • Quiet & Sturdy: Intelligent fan speed control reduces noise at low loads; compact size fits workbenches easily; durable housing withstands daily workshop use; built-in buzzer alarms for real-time faults.

Key Specifications

Parameter
Detail
Model
ET5300A
Channels
Single Channel
Rated Input
200W Power, 0-150V Voltage, 0-30A Current
Testing Modes
6 Basic Modes: CC, CV , CR, CP, CC+CV, CR+CV; 4 Professional Modes (Battery Test, LED Test, Dynamic Test, Scan Test)
Resolution
Voltage: 1mV (0.1-19.999V)/10mV (0.1-150.00V); Current: 1mA (0-30.00A); Resistance: 10mΩ (0.05Ω-1kΩ)/100mΩ (1kΩ-4.5kΩ); Power: 10mW (0-200W)
Accuracy
Voltage: ±(0.05%+0.02%FS); Current: ±(0.05%+0.05%FS); Power/Resistance: ±(0.1%+0.5%FS)
Battery Test
Discharge Modes: CC/CR; Max Capacity Measurement: 9999Ah
Dynamic Test
Modes: CC/CV; T1&T2 Range: 50ms-60s
Protection Functions
Over-Voltage (>21V/150V cut-off), Over-Current (>3.1A/31A cut-off), Over-Power (210W), Over-Temperature (85℃)
Connectivity & Power
USB + RS-232 interfaces (supports remote control + free upper computer software); External trigger input

Core Advantages

  • High-Precision Testing: 1mV/1mA resolution captures tiny signal changes, ensuring reliable data for R&D and production quality control.
  • Multi-Mode Adaptability: Covers basic constant tests to professional battery/LED/dynamic tests—one device replaces single-function tools.
  • Safe & Reliable: Multi-layer protection (over-voltage/current/power/temperature) safeguards both the load and tested devices from damage.
  • Convenient Data Management: Power-off data retention saves test parameters; remote control via USB/RS-232 fits automated testing setups.

Applicable Scenarios

  1. Production Line Testing: Quickly verify chargers/switch power supplies with PASS/FAIL function, improving inspection efficiency.
  1. Battery Industry: Test capacity, discharge performance, and internal resistance of lithium-ion, lead-acid, and other batteries.
  1. Electronic R&D: Use dynamic/scan modes to analyze power supply stability and prototype performance for new electronic designs.
  1. Education & Labs: Ideal for electronics courses—intuitive operation helps students master load testing principles and signal analysis.

Why Choose ET5300A ?

  • Precision You Can Trust: Low error rates meet professional testing standards, avoiding costly mistakes from inaccurate data.
  • User-Centric Design: Bilingual display, key lock, and quiet operation fit users of all experience levels and work environments.
  • Cost-Effective: Combines 10+ test functions in one device, saving space and budget vs. buying multiple tools.
Ready to upgrade your single-channel power testing? Click “Add to Cart”—the ET5300A’s high precision and versatility make it a must-have for engineers, production teams, and educators. Secure yours today!

Warranty

30-Day return and refund guarantee (Refer to our Refund Policy), 2-year warranty (only available for orders purchased directly from kuaiquinstrument.com), lifetime technique support by KUAIQU.
