Hantek 6104BD virtual Oscilloscope 4 Channels Arbitrary Waveform Generator 100MHz Bandwidth Powered By USB 2.0 Interface new original

Hantek 6104BD virtual Oscilloscope 4 Channels Arbitrary Waveform Generator 100MHz Bandwidth Powered By USB 2.0 Interface new original

$269.00 USD
$269.00 USD
Sale Sold out

English Manual

Hantek 6104BD Digital Oscilloscope: 4-Channel, 100MHz with Built-In Waveform Generator

Tired of switching between oscilloscopes and signal generators for testing? The Hantek 6104BD combines 4-channel oscilloscope (100MHz bandwidth) + 25MHz arbitrary waveform generator—ideal for electronics R&D, industrial diagnostics, and lab experiments!

Compact & Durable Design

175×105×25mm size, 0.9KG weight: portable for on-site testing, rugged housing resists workshop wear. Intuitive control layout cuts learning time, suitable for both beginners and pros.

Key Specifications

Parameter
Detail
Model
Hantek 6104BD
Oscilloscope Core

Channels
4 Digital Channels (simultaneous measurement)
Bandwidth
100MHz
Real-time Sampling Rate
1GSa/s
Memory Depth
64K
Input Impedance
1MΩ, 25pF
Input Sensitivity
2mV/div - 10V/div
Trigger Modes/Sources
Edge/Pulse/Video/Alternative; CH1-CH4
Signal Process
+, -, ×, ÷, FFT, Invert
Auto Measurement
Vpp, frequency, rise time, duty cycle (19+ parameters)
Waveform Generator

Output Channel
1 Channel
Bandwidth
25MHz
Sampling Rate
200MSa/s (DDS technology)
Vertical Resolution
12Bit
Waveform Types
Sine, square, triangle, sawtooth + editable arbitrary waveforms

Core Advantages

  • 2-in-1 Efficiency: 4-channel scope + waveform generator in one—no extra tools needed for signal testing & simulation.
  • 100MHz High Performance: Captures high-frequency signals (e.g., digital circuits, RF modules) with 1GSa/s sampling precision.
  • Flexible Signal Generation: 25MHz generator supports standard waveforms + custom edits, perfect for simulating real-world test scenarios.
  • Precise Analysis: FFT frequency breakdown + auto/cursor measurement for quick troubleshooting.

Use Scenarios

  1. Electronics R&D: Prototype testing, multi-circuit performance validation, and custom signal simulation.
  1. Industrial Repair: Diagnose control systems, motors, and power supplies—generate test signals to verify component functionality.
  1. Education & Labs: Teach signal analysis, oscilloscope operation, and waveform generation principles.

Why Choose 6104BD?

  • Versatility: Covers testing (scope) + simulation (generator) needs, saving cost vs. two separate tools.
  • Pro-Grade Performance: 100MHz bandwidth + 12Bit generator resolution meets industrial/ lab standards.
  • Portable & Durable: Works on benches or field sites—ideal for mobile engineers.
Ready to streamline your testing workflow? Click “Add to Cart”—the Hantek 6104BD’s 2-in-1 power and precision make it a pro’s must-have!
