Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity

Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity

$229.00
$229.00
Please hurry! Only 10 left in stock
Subtotal: $229.00
10 customers are viewing this product

Storewide Discounts

Spend $100+ for 10% OFF | $300+ for 15% OFF | $400+ for 20% OFF. Discounts will be automatically deducted at checkout.

Free Shipping

We offer free express shipping on all orders.

You'll receive your order an estimated 7-15 working days after shipment.

Free Returns

30-Day return and refund guarantee refer to our refund policy.
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity

Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity

$229.00
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity
Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity

Hantek 6074BD 4CH Oscilloscope Function and Arbitrary Waveform Generator 70MHZ 1GSa/s 2mV-10V/DIV Input Sensitivity

$229.00
Product Details

English Manual

Hantek 6074BD Digital Oscilloscope: 4 - Channel Powerhouse with Arbitrary Waveform Generator

Struggling with basic oscilloscopes that can't meet diverse testing needs? The Hantek 6074BD is a game - changer, offering 4 - channel functionality, 70MHz bandwidth, and an integrated arbitrary waveform generator. Ideal for electronics development, industrial diagnostics, and educational experiments!

Compact and Robust Design

With dimensions of 175mm * 105mm * 25mm and weighing 0.9KG, the Hantek 6074BD is designed to be portable yet sturdy. Its durable build can withstand the rigors of daily use, whether in a well - equipped lab or on a bustling factory floor. The intuitive control layout makes it easy to operate, allowing both beginners and seasoned professionals to get the most out of it with minimal effort.

Key Specifications

Parameter
Detail
Model
Hantek 6074BD
Channels
4 Digital Channels (simultaneous measurement)
Bandwidth
70MHz
Real - time Sampling Rate
1GSa/s
Memory Depth
64K
Time Base Precision
±50ppm
Time Base Range
2ns/div - 1000s/div (1 - 2 - 4 sequences)
Input Impedance
1MΩ, 25pF
Input Sensitivity
2mV/div - 10V/div
Vertical Resolution
8Bit
Vertical Displacement Range
2mV - 10V/div @×1 probe; 20mV - 100V/div @×10 probe; 200mV - 1000V/div @×100 probe; 2V - 10000V/div @×1000 probe
DC Gain Accuracy
±3%
Bandwidth Limit
20MHz
Trigger Mode
Edge, Pulse, Video, Alternative
Trigger Source
CH1, CH2, CH3, CH4
Waveform Signal Process
+, -, ×, ÷, FFT, Invert
Cursors Measurement
Cross, Trace, Horizontal, Vertical
Auto Measurement
Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle
Arbitrary Waveform Generator
25MHz (1 channel), 200MSa/s DDS, 12 - bit vertical resolution, built - in standard waveforms, arbitrary waveform editable
Accessories
2 passive probes, 2 gator clip lines

Core Functions

  • 4 - Channel Multitasking: Simultaneously test up to 4 signals, enabling comprehensive analysis of complex circuits like power management systems and microcontroller - based designs. No need to switch probes constantly, saving valuable testing time.
  • 70MHz Bandwidth: Accurately capture and display signals up to 70MHz, making it suitable for a wide range of applications, from audio frequency testing to basic digital circuit analysis.
  • Integrated Arbitrary Waveform Generator: Generate a variety of standard waveforms (sine, square, triangle, etc.) and customize arbitrary waveforms easily. Ideal for simulating different signal conditions during circuit testing and development.
  • Advanced Signal Processing: Use FFT for frequency - domain analysis, along with arithmetic operations and auto - measurement functions, to quickly and accurately assess signal characteristics and troubleshoot issues.

Applicable Scenarios

  1. Electronics Development: In the design and prototyping phase, the Hantek 6074BD helps engineers test circuit functionality, verify component performance, and optimize designs. The arbitrary waveform generator is especially useful for creating test signals tailored to specific requirements.
  1. Industrial Diagnostics: For industrial maintenance technicians, it aids in diagnosing faults in control systems, motors, and power supplies. The ability to analyze multiple signals simultaneously speeds up the troubleshooting process.
  1. Educational Use: In educational institutions, it serves as an excellent teaching tool for students learning about electronics, electrical engineering, and signal analysis. The intuitive interface and diverse features make it easy for students to grasp complex concepts.

Why Choose Hantek 6074BD?

  • Versatility: The combination of 4 - channel oscilloscope and arbitrary waveform generator in one device offers unparalleled flexibility, reducing the need for multiple testing instruments.
  • Performance: With its 70MHz bandwidth, high sampling rate, and accurate measurement capabilities, it delivers reliable results for a wide range of testing tasks.
  • Value - for - money: Get the functionality of multiple tools at a reasonable price, making it a cost - effective choice for professionals and hobbyists alike.
Ready to enhance your testing capabilities? Click “Add to Cart” now and equip yourself with the Hantek 6074BD. Don't miss out on this opportunity to own a powerful and versatile digital oscilloscope!
