Hantek6022BL USB Oscilloscope & Logic Analyzer: 2-in-1 Precision for On-the-Go Testing

Tired of carrying separate oscilloscopes and logic analyzers for testing? The Hantek6022BL combines 2-channel oscilloscope + 16-channel logic analyzer—ideal for embedded systems, digital circuits, and field maintenance!

Product Design

Anodized aluminum casing (same as iPad) blends style with durability: boosts surface hardness, resists wear, and ensures good heat dissipation. Compact size (200×100×35mm) and lightweight (0.3KG) fit laptop bags easily, perfect for on-site work or business trips.

Key Specifications

Parameter
Detail
Model
Hantek6022BL
Oscilloscope Features

Channels
2 Digital Channels
Bandwidth
20MHz
Max Sample Rate
48MSa/s
Memory Depth
1M
Rise Time
17.5ns
Time Base Range
1ns/div - 5000s/div (1-2-5 step)
Input Impedance
1MΩ 25pF
Input Sensitivity
20mV/div ~ 5V/div
DC Accuracy
±3%
Trigger Source
CH1, CH2
Math Functions
+, -, ×, ÷, FFT, Invert
Logic Analyzer Features

Channels
16 Channels
Bandwidth
10MHz
Max Impedance
1MΩ (C=7.5pF)
Max Input Voltage
0V ~ 5.5V
Compatible Input
TTL, LVTTL, CMOS
Memory Depth
1M/CH
General Features

Power Supply
USB Port (no external power needed)
Compatible OS
Windows 7, 8, 10

Core Functions

  • 2-in-1 Testing: 2-channel oscilloscope for analog signal analysis + 16-channel logic analyzer for digital circuits—one tool covers mixed-signal testing.
  • USB-Powered Convenience: Plug-and-play via USB, works with laptops; no bulky adapter, ideal for field or remote testing.
  • Rich Measurement Tools: 20 auto-measurement functions (Vpp, frequency, rise time, etc.) + cross/horizontal/vertical cursor measurement for precise data.
  • Flexible Data Saving: Export waveforms as text, JPG/BMP, or MS Excel/Word files—easy to document and share results.

Applicable Scenarios

  1. Embedded System Testing: Analyze analog signals (e.g., sensor outputs) and digital logic (e.g., MCU communication) simultaneously.
  1. Digital Circuit Debugging: Use 16 logic channels to test TTL/LVTTL/CMOS circuits, perfect for Arduino/Raspberry Pi projects.
  1. Field Maintenance: Troubleshoot product lines or repair electronics on-site—portable design fits tight spaces.
  1. Education & Hobby: Learn mixed-signal analysis; suitable for students or DIY enthusiasts testing analog-digital hybrid circuits.

Why Choose Hantek6022BL?

  • All-in-One Efficiency: Combines oscilloscope and logic analyzer, saves cost and carrying hassle.
  • Portable & Practical: USB-powered, compact, and lightweight—free from bench constraints.
  • Reliable Performance: 20MHz oscilloscope bandwidth + 10MHz logic analyzer bandwidth covers most mid-level testing needs.
Ready to simplify mixed-signal testing? Click “Add to Cart”—the Hantek6022BL’s 2-in-1 functionality and portability make it a must-have for engineers, technicians, and hobbyists. Secure yours today!

Warranty

30-Day return and refund guarantee (Refer to our Refund Policy), 2-year warranty (only available for orders purchased directly from kuaiquinstrument.com), lifetime technique support by KUAIQU.
