Product Details

Lead Type Testing Fixture 35A52: Reliable Testing for Leaded Components

Need stable testing for leaded electronic components? The Lead Type Testing Fixture 35A52 features adjustable lead clamping and high-conductivity contacts, enabling accurate measurement of resistors, capacitors, diodes, and transistors—ideal for electronics labs, component inventory checks, and production line QC.

User-Friendly Design

  • Adjustable Clamping: Flexible jaw spacing (5~30mm) fits various leaded component sizes; non-slip grip prevents lead damage.
  • Durable Build: Brass contacts (anti-oxidation, low resistance) + high-impact PP housing; withstands frequent industrial use.
  • Easy Operation: Plug-and-test with most multimeters/LCR meters; compact size (fits bench/portable setups) and one-hand operation.

Key Specifications

Parameter
Detail
Model
Lead Type Testing Fixture 35A52
Lead Compatibility
Leaded components (resistors, capacitors, diodes, transistors); lead diameter: 0.3~1.2mm
Clamping Range
5~30mm (adjustable jaw spacing for different component sizes)
Contact Material
Brass (nickel-plated, high conductivity, anti-corrosion)
Compatibility
Works with multimeters, LCR meters (e.g., ET32 series, Fluke, Keysight)
Housing Material
High-impact PP plastic (wear-resistant, insulation protection)
Dimensions
85×55×40mm (compact, space-saving)
Weight
~110g (lightweight for portability)

Core Advantages

  • Stable Contact: Brass contacts reduce resistance interference, ensuring accurate test data.
  • Versatile Sizing: Adjustable clamping fits most leaded components, no need for multiple fixtures.
  • Safe & Durable: Insulated housing + non-slip grip protects users and prevents component damage.

Applicable Scenarios

  1. Component Testing: Measure resistance, capacitance, or diode forward voltage of leaded parts.
  1. Inventory QC: Verify component parameters during stock checking or incoming inspection.
  1. Production Line: Quick functionality tests for leaded components before PCB assembly.
  1. Lab R&D: Validate leaded component performance in prototype circuit debugging.

Why Choose Lead Type Testing Fixture 35A52?

  • Leaded-Specific Design: Solves "unstable hand-holding" issues for leaded component testing.
  • Cost-Effective: Upgrades existing meters to test leaded parts; no need for specialized equipment.
  • Practical & Portable: Compact size and lightweight design suit lab, workshop, or on-site use.
Boost your leaded component testing efficiency! Click “Add to Cart” to get the Lead Type Testing Fixture 35A52.
