ET433 Inductance/capacitor measurement Universal Lcr Meter circuit Capacitance Inductance Resistance Meter

ET433 Inductance/capacitor measurement Universal Lcr Meter circuit Capacitance Inductance Resistance Meter

$479.99 USD
$959.98 USD $479.99 USD
Promotion Épuisé
Frais d'expédition calculés à l'étape de paiement.

English Manual

ET433 Handheld LCR Meter: 0.1% Ultra-Precision for Premium Testing

Need top-tier L/C/R accuracy? The ET433 delivers 0.1% basic accuracy, 0.1Hz-500kHz frequency, 3.0-inch HD display—ideal for aerospace, medical R&D, automotive high-voltage testing, and precision production!

User-Friendly & Portable Design

  • Clear Display: 3.0-inch HD TFT (6-digit) shows L/C/R/Z + X/D/Q/theta/ESR/ESL/CR; bilingual + auto-brightness.
  • Easy Operation: Shortcut keys; 1/s-15/s measuring speed; one-key calibration (with reminder); auto/manual range lock.
  • Durable & Portable: 4000mAh battery (15+ hrs); IP54 dustproof/splashproof; compact (180×95×45mm) with anti-slip grip.

Key Specifications

Parameter
Detail
Model
ET433
Basic Accuracy
0.1%
Test Frequency
0.1Hz-500kHz (13 bands)
Measurement Params
Main: L/C/R/Z; Sub: X/D/Q/theta/ESR/ESL/CR
Range
L:0.000μH~20000H; C:0.000pF~200.000mF; R:0.000001Ω~2000.00MΩ
Special Modes
Capacitor/inductor tests; deviation/screening (0.001%-500%); temp comp (-20℃~80℃); 5000-group storage
Bias Voltage/Test Level
0-5000mV (0.1mV step); 0.02-2.0Vrms
Power & Connectivity
4000mAh (2h fast charge); USB 3.0 + Bluetooth 5.0 (SCPI); auto-shutdown (1-120min)

Core Advantages

  • Top Precision: 0.1% accuracy + wide frequency captures nano-level component changes.
  • Versatile: Inductor saturation test, 5000-group storage; IP54 + temp comp for harsh environments.
  • Smart & Portable: 15+ hrs battery; wireless sync simplifies R&D/production reports.

Applicable Scenarios

  1. Aerospace/Medical: Test precision capacitors/coils; pinpoint micro-faults.
  1. Automotive: Screen high-voltage components with 0.001% limits.
  1. R&D Labs: 0.1Hz-500kHz for sensor/5G component analysis; 5000-group data tracking.
  1. Fieldwork: On-site testing (wind turbines/medical devices) with IP54 protection.

Why Choose ET433?

  • Premium Performance: Meets AS9100/ISO 13485 standards for high-stakes use.
  • All-in-One: Replaces specialized tools; saves space/cost.
  • Full Accessories: USB, fast charger, probes; optional Kelvin clip/high-voltage leads.
Ready for premium testing? Click “Add to Cart”—the ET433’s accuracy and versatility suit aerospace/medical/automotive teams!
