RIGOL DSA815 DSA815-TG Spectrum Analyzer 9kHz~1.5GHz High Frequency 9kHz - 1.5GHz Resolution 10Hz - 1MHz

$1,399.00 USD

Promotion Épuisé

Frais d'expédition calculés à l'étape de paiement.

Model DSA815 DSA815-TG

Quantité

English Mannel

Overview

RIGOL's DSA815 and DSA815-TG are high - performance spectrum analyzers, ideal for precise signal analysis in electronics, telecommunications, and research.

Key Features

Low Resolution Bandwidth: Down to 10Hz, enabling effective distinction of adjacent equal - amplitude signals.

Low Noise Floor: Display average noise level as low as - 155dBm, reducing impact on weak signal testing.

EMI Pre - Compliance Measurement: With EMI filter (6dB) and quasi - peak detector for accurate EMI prediction and diagnosis.

VSWR Measurement: Complete voltage standing wave ratio testing with tracking source (for DSA815 - TG) and VSWR bridge.

Powerful Software: Ultra Spectrum DSA series software for control, data transmission, and advanced display/analysis.

Technical Specifications

Parameter	DSA815	DSA815 - TG
Frequency Range	9kHz - 1.5GHz	9kHz - 1.5GHz
Resolution	10Hz - 1MHz	10Hz - 1MHz
Bandwidth Phase Noise	- 80dBc/Hz@10kHz	- 80dBc/Hz@10kHz
Display Average Noise Level	- 155dBm	- 155dBm
With Tracking Source	No	Yes

Selection Tips

Choose DSA815 if you need basic spectrum analysis without voltage standing wave ratio testing.

Opt for DSA815 - TG when you require voltage standing wave ratio testing with the tracking source function.

Application Scenarios

Telecommunications: Analyze wireless communication signals.

Electronics R & D: Test and debug electronic circuits with signal analysis.

EMI Testing: Conduct pre - compliance electromagnetic interference testing.

Education: Teach spectrum analysis principles in electronics courses.

Research Labs: Perform precise signal analysis for scientific experiments.

RF Component Testing: Test radio frequency components like antennas with VSWR measurement (DSA815 - TG).

Get RIGOL DSA815 or DSA815 - TG now for precise signal analysis!
