IP100 Oscilloscope Probe: Struggling with Inaccurate Signal Readings?
Fed up with oscilloscope probes that deliver fuzzy waveforms, lack precision, or can't handle a wide range of signals? The IP100 Oscilloscope Probe is here to revolutionize your signal - testing experience!
Appearance & Structure
The IP100 features a sleek, ergonomic design that fits comfortably in your hand, reducing fatigue during extended use. Its durable construction, with a 122 - cm (48 - inch) cable length, ensures reliable connectivity in various testing scenarios. The injection - molded integration not only enhances its build quality but also makes it resistant to wear and tear.
Product Parameters
Parameter
Detail
Model
IP100
Attenuation Ratio
x1/x10
Input Resistance
1 MΩ for x1 & 10 MΩ for x10
Input Capacitance
x1: 105 pf ~ x10: 15pf
Compensation Range
10 pf - 20 pf
System Bandwidth
DC - 100 MHz
Output Voltage
x1: 150V DC + peak AC; x10: 300 Vms
Operating Temperature Range
0 °C - 50 °C
Humidity
≤ 80% (relative humidity)
Function Introduction
Versatile Attenuation Modes: Easily switch between x1 and x10 attenuation ratios using the convenient switch. The x1 mode is perfect for measuring low - voltage signals accurately, while the x10 mode is designed to handle higher - voltage signals without distortion.
Wide - Bandwidth Performance: With a system bandwidth of DC - 100 MHz, the IP100 can capture and display high - frequency signals with exceptional clarity. Whether you're working on high - speed digital circuits or analyzing complex analog waveforms, this probe has you covered.
Precise Input Characteristics: The carefully calibrated input resistance and capacitance values ensure minimal signal interference. The 1 MΩ input resistance for x1 and 10 MΩ for x10, along with the low - capacitance values, provide accurate signal transfer from the source to your oscilloscope.
Flexible Compensation: The 10 pf - 20 pf compensation range allows you to fine - tune the probe to match different oscilloscope inputs. This ensures optimal signal integrity and accurate waveform representation, reducing the chances of measurement errors.
Applicable Scenarios
Electronics Circuit Design: Ideal for designers to test and debug circuit boards. Measure signal levels, check for voltage drops, and analyze waveform shapes during the prototyping and development stages.
Electrical Engineering Education: Teachers and students can use the IP100 to learn about signal analysis, electrical principles, and oscilloscope operation. Its user - friendly design and versatile functions make it a great educational tool.
Automotive Electronics Repair: When troubleshooting car electrical systems, from engine control units to infotainment systems, the IP100 can accurately measure signals, helping technicians identify and fix issues efficiently.
Consumer Electronics Repair: Whether it's repairing smartphones, laptops, or other consumer devices, this probe can be used to test components, check for short circuits, and ensure proper signal flow.
Why Choose the IP100 Oscilloscope Probe?
Accuracy and Precision: The carefully engineered parameters and wide - bandwidth capabilities guarantee accurate signal measurements, allowing you to make informed decisions in your work.
Durability: The robust construction, including the injection - molded integration and long - lasting cable, ensures the probe can withstand the rigors of daily use in various environments.
Versatility: With its dual - attenuation modes and flexible compensation, the IP100 can adapt to different signal levels and oscilloscope setups, making it a one - size - fits - most solution for your signal - testing needs.
Ready to upgrade your oscilloscope's performance? Click “Add to Cart” now and experience the difference the IP100 Oscilloscope Probe can make. Don't miss out on this opportunity to enhance your signal - testing accuracy and efficiency. Stock is limited, so secure yours today!
