Handheld Battery Tester 0.01mΩ - 200.0kΩ 0.01mΩ - 2.2kΩ Battery voltage internal resistance tester LCD display U disk storage Correction function

Handheld Battery Tester 0.01mΩ - 200.0kΩ 0.01mΩ - 2.2kΩ Battery voltage internal resistance tester LCD display U disk storage Correction function

$799.00; $799.00
Precio unitario: por

¡Por favor, date prisa! 10 queda en stock

Measurement range: 0.1mΩ~200.00Ω 0.1mΩ~200.00Ω 0.1mΩ~2.2kΩ

Variantes de producto

Cantidad:

Total parcial: $799.00

10 Los clientes están viendo este producto.

Storewide Discounts

Spend $100+ for 10% OFF | $300+ for 15% OFF | $400+ for 20% OFF. Discounts will be automatically deducted at checkout.

Envío gratis

We offer free express shipping on all orders.

You'll receive your order an estimated 7-15 working days after shipment.

Devoluciones gratuitas

30-Day return and refund guarantee refer to our refund policy.

Handheld Battery Tester 0.01mΩ - 200.0kΩ 0.01mΩ - 2.2kΩ Battery voltage internal resistance tester LCD display U disk storage Correction function

$799.00

Elige opciones

Cantidad:

Handheld Battery Tester 0.01mΩ - 200.0kΩ 0.01mΩ - 2.2kΩ Battery voltage internal resistance tester LCD display U disk storage Correction function

$799.00

Measurement range: 0.1mΩ~200.00Ω 0.1mΩ~200.00Ω 0.1mΩ~2.2kΩ

Variantes de producto

Detalles del producto
Garantía
Garantía de precio

Detalles del producto

English Manual

Overview

This handheld battery internal resistance tester is a high - performance instrument designed for accurate measurement of battery parameters. It caters to diverse battery testing needs in various scenarios, ensuring precise and reliable assessment of battery conditions.

Key Features

Dual Parameter Testing: Capable of testing AC resistance and DC voltage, providing comprehensive battery parameter information.

High Measurement Accuracy: Offers resistance accuracy of 0.5% ± 5dgt (with a resolution of 0.01mΩ) and voltage accuracy of 0.1% ± 5dgt (with a resolution of 1mV), ensuring reliable measurement results.

Low - Harm Signal Source: Utilizes an AC 1kHz signal source with an open - circuit voltage < 30mV, reducing harm to the tested battery, and a test current < 15mA.

Flexible Range Modes: Comes with automatic, manual, and nominal test range modes. One model has six - range options, and the other has four - range options to adapt to different battery specifications.

Multiple Test Speeds: Provides various test speeds. One model offers speeds of 20 times/second, 10 times/second, and 3 times/second, while the other has a speed of 2 times/second to meet different testing efficiency requirements.

Diverse Result Displays: Supports absolute deviation (ABS), relative deviation (PER), and sequence (SEQ) comparison modes for flexible result presentation.

Calibration Function: Features full - range short - circuit zeroing function for accurate measurement calibration.

Comparator Function: Allows for separate voltage comparison, separate resistance comparison, and combined voltage - resistance comparison. Displays GD/NG sorting results and has an audible alarm.

Multiple Trigger Modes: Supports internal trigger, manual trigger, and remote trigger for flexible testing operation.

Versatile Interfaces: Equipped with built - in Mini - USB (virtual serial port), charging interface, and U - disk interface for convenient data transfer and device charging.

Long - Lasting Battery: Powered by an 8.4V 2200mAh lithium battery for long - term operation.

User - Friendly Display and Functions: Features a 3.5 - inch true - color LCD display. Includes keyboard lock, data hold function, SCPI command set compatibility, Chinese - English switching, backlight adjustment, ultra - long standby with automatic shutdown, and one - key saving of 500 groups of measurement data.

Technical Specifications

Parameter	Model 1	Model 2
Test Parameters	AC resistance, DC voltage	AC resistance, DC voltage
Basic Accuracy (Resistance)	0.5% ± 5dgt (resolution 0.01mΩ)	0.5% ± 5dgt (resolution 0.01mΩ)
Basic Accuracy (Voltage)	0.1% ± 5dgt (resolution 1mV)	0.1% ± 5dgt (resolution 1mV)
Resistance Measurement Range	0.1mΩ - 200.0Ω	0.01mΩ - 2.2kΩ
Voltage Measurement Range	1mV - 50V	1mV - 50V
Signal Source	AC 1kHz, open - circuit voltage < 30mV, test current < 15mA	AC 1kHz, open - circuit voltage < 30mV, test current < 15mA
Range Modes	Four - range automatic, manual, nominal test	Six - range automatic, manual, nominal test
Test Speed	2 times/second	20 times/second, 10 times/second, 3 times/second
Maximum Readings (Resistance)	3200 counts	2200 counts
Maximum Readings (Voltage)	3000 counts	5000 counts
Calibration	Full - range short - circuit zeroing	Full - range short - circuit zeroing
Comparator	Voltage separate comparison, resistance separate comparison, voltage - resistance combined comparison; GD/NG sorting result display, audible alarm	Voltage separate comparison, resistance separate comparison, voltage - resistance combined comparison; GD/NG sorting result display, audible alarm
Triggers	Internal trigger, manual trigger, remote trigger	Internal trigger, manual trigger, remote trigger
Interfaces	Mini - USB (virtual serial port), charging interface, U - disk interface	Mini - USB (virtual serial port), charging interface, U - disk interface
Power Requirements	Input: 100 - 240V ~ 50/60Hz 0.35A; Output: 9V 1A DC; 8.4V 2200mAh lithium battery	Input: 100 - 240V ~ 50/60Hz 0.35A; Output: 9V 1A DC; 8.4V 2200mAh lithium battery
Dimensions (mm)	130.23 (W) × 210.76 (H) × 37.88 (D)	130.23 (W) × 210.76 (H) × 37.88 (D)
Weight	650g	650g

Application Scenarios

Battery Manufacturing Quality Control: Tests the internal resistance and voltage of batteries during production to ensure product quality.

Battery Recycling and Sorting: Assesses the condition of used batteries by measuring internal resistance and voltage for effective recycling and sorting.

Electric Vehicle Battery Inspection: Inspects the battery packs of electric vehicles to ensure their performance and safety.

Uninterruptible Power Supply (UPS) Maintenance: Measures the internal resistance of UPS batteries to predict their service life and ensure reliable power supply.

Portable Electronic Device Battery Testing: Tests the batteries of portable electronic devices such as mobile phones and laptops to assess their health.

Battery Research and Development Labs: Used in research labs to test and analyze new battery technologies and prototypes.

Get this handheld battery internal resistance tester now for accurate and efficient battery parameter measurement!
